Bilstein Shock Absorbers

Bilstein ASM Series shock absorbers are designed to provide next level performance for the Resto-Mod and Pro-Touring market. With a variety of damper lengths to fit most popular applications, the shocks combine a great street-worthy ride quality with top level motorsports handling characteristics for a true total package. This modular aluminum design with a threaded shock body dissipates heat quickly. The hard-anodized coating reduces internal friction, and improves strength and durability. The ASM Series dampers are available in non, single and double adjustable configurations for premium tuning options to best fit your budget and driving demands.

Additional Attributes:

GTIN: 00651860874838
Adjustable Damping: Single Adjustable – Rebound
Body Design: Threaded Body Screw Top (Coilover)
Body Diameter (ID): 46mm
Body Material: Aluminum
Boot Included: No
Collapsed Length (IN): 15.24
Collapsed Length (MM): 387.2
Extended Length (IN): 22.32
Extended Length (MM): 566.9
Finish: Clear Anodized
Internal Design: Monotube
Lower Mount Type: 1/2in heim
PartType: Shocks / Struts
Piston Type: Digressive
Prop 65 (Y/N): Y
Prop 65 – Short Label: WARNING: Cancer & Reproductive Harm – www.P65Warnings.ca.gov
Segment: Motorsports
Series: ASM Series
Spring Seat Included: Yes
Upper Mount Type: 1/2in heim

Extended Information:

Emissions : CARB Eligible
Life Cycle Status: Available To Order

Packaging:

Quantity of Each: 1.0
Package UOM: EA
Dimension: 26.8000 x 2.9500 x 2.9500 inches
Weight: 7.0000 PG

PDF:

USA SDS_Shock_Air Spring_V2_EN
