The Centerforce(R) DFX(R) Clutch Series is the competition-proven clutch package for select import and domestic applications. This DFX series is engineered for competition standards of quality and craftsmanship. The DFX series is aimed at high-end applications that continually demand increased integrity and holding-capacity. DFX scores big, not only with holding-capacity and strength, but also provides some of the best drivability from a race-inspired single disc clutch. The DFX series features the patented Centerforce centrifugal weight system (where applicable) and retains an easy pedal effort, thanks to Centerforce's patented ball bearing actuated diaphragm, for smooth engagements without detriment to the vehicle's release components. The Centerforce DFX performance clutch system is SFI approved for competition with Nodular Iron pressure plate rings and reinforcements designed to help prevent drive strap breakage and safety. Note: Due to the materials used, the DFX clutch series is more aggressive with less dampening; this can cause some additional drive train noise and/or chatter.
Additional Attributes:
GTIN: 00788442037548
Alignment Tool Included9: Yes
California Proposition 65: WARNING – includes Nickel – cancer. www.P65Warnings.ca.gov.
Clutch Bolt Pattern6: 22
Clutch Bolt Type7: with Shoulder Bolt
Clutch Disc Diameter8: 12.25
Counterweight Assist2: Yes
Crankshaft Bolt Hole Quantity7: 8
Disc Material4: Cerametallic
Disc Quantity0: 1
Disc Type Sprung Solid: Sprung
Disc Type5: 8-Paddle
Input Shaft Diameter1: 1-1/4
Input Spline Quantity3: 10
Made In The USA9: Assembled
Material2: Cast Iron Pressure Plate / Cerametallic Button Style Friction
Mounting Hardware Included0: Yes
Out of Package Weight: 93.3
Pilot Bushing Included7: Yes
Release Bearing Included5: Yes
Ring Gear O.D.7: 15.625
SFI 1.1 Approved: N
Tooth Quantity: 152
Torque Capacity: 900
Extended Information:
Emissions : CARB Eligible
Life Cycle Status: Available To Order
Packaging:
Quantity of Each: 1
Package UOM: EA
Dimension: 18 x 18 x 13 inches
Weight: 96.5 PG
