The Centerforce(R) Dual Friction(R) Clutch Series is a performance matched pressure plate & disc combination featuring the patented Centerforce centrifugal weight system (where applicable) and specialized machining processes to provide a performance clutch that offers exceptional street characteristics, while offering outstanding holding-capacity and durability. Furthermore, the Centerforce Dual Friction disc has an organic full facing on one side for longevity and an organic segmented facing on the other side providing increased holding capacity. Some applications have the organic segmented facings of both sides. The Dual Friction clutch is engineered for those who are looking for the ultimate in street/strip holding power and performance without sacrificing pedal effort and driver control. While the Dual Friction has been engineered primarily as a street clutch it can be used in mild competition applications.
Additional Attributes:
GTIN: 00788442037579
Alignment Tool Included9: Yes
California Proposition 65: WARNING – includes Nickel – cancer. www.P65Warnings.ca.gov.
Clutch Bolt Pattern6: 22
Clutch Bolt Type7: with Shoulder Bolt
Clutch Disc Diameter8: 12.25
Counterweight Assist2: Yes
Crankshaft Bolt Hole Quantity7: 8
Disc Material4: Organic/Carbon Composite
Disc Quantity0: 1
Disc Type Sprung Solid: Sprung
Disc Type5: Segmented face
Input Shaft Diameter1: 1-1/4
Input Spline Quantity3: 10
Made In The USA9: Assembled
Material2: Cast Iron Pressure Plate / Full Face and Segmented Organic Friction
Mounting Hardware Included0: Yes
Out of Package Weight: 93.20
Release Bearing Included5: Yes
Ring Gear O.D.7: 15.625
Tooth Quantity: 152
Torque Capacity: 1153
Extended Information:
Emissions : CARB Eligible
Life Cycle Status: Available To Order
Packaging:
Quantity of Each: 1
Package UOM: EA
Dimension: 18 x 18 x 13 inches
Weight: 92.4 PG
